ZHCU948B September   2020  – May 2022 BQ76952



  1.   使用前必读
    1.     电池表示法约定
    2.     商标
    3.     术语表
  2. 引言
  3. 器件描述
    1. 2.1 概述
    2. 2.2 功能方框图
  4. 器件配置
    1. 3.1 直接命令和子命令
    2. 3.2 使用 OTP 或寄存器进行配置
    3. 3.3 数据格式
      1. 3.3.1 无符号整数
      2. 3.3.2 整数
      3. 3.3.3 浮点
      4. 3.3.4 十六进制
  5. 测量子系统
    1. 4.1  电压测量
      1. 4.1.1 电压测量时间表
      2. 4.1.2 电芯与互连的 VC 引脚的使用情况
      3. 4.1.3 电芯互连电阻
    2. 4.2  通用的 ADCIN 功能
    3. 4.3  库仑计数器和数字滤波器
    4. 4.4  同步电压和电流测量
    5. 4.5  子命令 0x0071–0x0074 DASTATUS1-4()、电芯电压和同步电流计数
    6. 4.6  子命令 0x0075–0x0077 DASTATUS5–7()、其他测量值
    7. 4.7  内部温度测量
    8. 4.8  热敏电阻温度测量
    9. 4.9  电压 ADC 的出厂修整
    10. 4.10 电压校准(ADC 测量)
    11. 4.11 电压校准(COV 保护和 CUV 保护)
    12. 4.12 电流校准
    13. 4.13 温度校准
  6. 初级和次级保护子系统
    1. 5.1 保护概述
    2. 5.2 初级保护
      1. 5.2.1  初级保护概述
      2. 5.2.2  高侧 NFET 驱动器
      3. 5.2.3  保护 FET 配置和控制
        1. 5.2.3.1 FET 配置
        2. 5.2.3.2 FET 控制
          1. 5.2.3.2.1 PRECHARGE 模式
          2. 5.2.3.2.2 PREDISCHARGE 模式
      4. 5.2.4  电芯过压保护
      5. 5.2.5  电芯欠压保护
      6. 5.2.6  放电短路保护
      7. 5.2.7  充电过流保护
      8. 5.2.8  放电过流 1、2 和 3 保护
      9. 5.2.9  充电过热保护
      10. 5.2.10 放电过热保护
      11. 5.2.11 过热 FET 保护
      12. 5.2.12 内部过温保护
      13. 5.2.13 充电低温保护
      14. 5.2.14 放电低温保护
      15. 5.2.15 内部欠温保护
      16. 5.2.16 主机看门狗保护
      17. 5.2.17 预充电超时保护
      18. 5.2.18 负载检测功能
    3. 5.3 次级保护
      1. 5.3.1  次级保护概述
      2. 5.3.2  铜沉积 (CUDEP) 永久失效
      3. 5.3.3  欠压安全 (SUV) 永久失效
      4. 5.3.4  过压安全 (SOV) 永久失效
      5. 5.3.5  充电过流安全 (SOCC) 永久失效
      6. 5.3.6  放电过流安全 (SOCD) 永久失效
      7. 5.3.7  电芯过热安全 (SOT) 永久失效
      8. 5.3.8  FET 过热安全 (SOTF) 永久失效
      9. 5.3.9  充电 FET (CFETF) 永久失效
      10. 5.3.10 放电 FET (DFETF) 永久失效
      11. 5.3.11 二级保护器 (2LVL) 永久失效
      12. 5.3.12 静止模式电压不平衡 (VIMR) 永久失效
      13. 5.3.13 运行时电压不平衡 (VIMA) 永久失效
      14. 5.3.14 放电短路锁存永久失效
      15. 5.3.15 OTP 存储器签名永久失效
      16. 5.3.16 数据 ROM 存储器签名永久失效
      17. 5.3.17 指令 ROM 存储器签名永久失效
      18. 5.3.18 LFO 振荡器永久失效
      19. 5.3.19 电压基准永久失效
      20. 5.3.20 VSS 永久失效
      21. 5.3.21 保护比较器多路复用器永久失效
      22. 5.3.22 命令的永久失效
      23. 5.3.23 电池组顶部电压测量检查
      24. 5.3.24 电芯开路
  7. 器件状态和控制
    1. 6.1 0x00 Control Status() 和 0x12 Battery Status() 命令
    2. 6.2 0x0070 MANU_DATA() 命令
    3. 6.3 LDO
      1. 6.3.1 前置稳压器控制
      2. 6.3.2 REG1 和 REG2 LDO 控制
    4. 6.4 多功能引脚控制
    5. 6.5 CFETOFF、DFETOFF 和 BOTHOFF 引脚功能
    6. 6.6 ALERT 引脚运行
    7. 6.7 DDSG 和 DCHG 引脚运行
    8. 6.8 保险丝驱动
    9. 6.9 器件事件时序
  8. 工作模式
    1. 7.1 概述
    2. 7.2 NORMAL 模式
    3. 7.3 SLEEP 模式
    4. 7.4 DEEPSLEEP 模式
    5. 7.5 SHUTDOWN 模式
    6. 7.6 CONFIG_UPDATE 模式
  9. 器件安全性
    1. 8.1 概述
  10. 串行通信接口
    1. 9.1 串行通信概述
    2. 9.2 I2C 通信子系统
    3. 9.3 SPI 通信接口
      1. 9.3.1 SPI 协议
    4. 9.4 HDQ 通信接口
  11. 10电池平衡
    1. 10.1 电芯平衡操作
    2. 10.2 电芯平衡时序
  12. 11诊断
    1. 11.1 诊断概述
    2. 11.2 VREF2 与 VREF1 检查
    3. 11.3 VSS 测量
    4. 11.4 电池组顶部电压测量检查
    5. 11.5 LFO 振荡器监控器
    6. 11.6 保护比较器多路复用器检查
    7. 11.7 内部看门狗复位
    8. 11.8 内部存储器检查
  13. 12命令和子命令
    1. 12.1 直接命令
    2. 12.2 直接命令的位字段定义
      1. 12.2.1  控制状态寄存器
      2. 12.2.2  Safety Alert A 寄存器
      3. 12.2.3  Safety Status A 寄存器
      4. 12.2.4  Safety Alert B 寄存器
      5. 12.2.5  Safety Status B 寄存器
      6. 12.2.6  Safety Alert C 寄存器
      7. 12.2.7  Safety Status C 寄存器
      8. 12.2.8  PF Alert A 寄存器
      9. 12.2.9  PF Status A 寄存器
      10. 12.2.10 PF Alert B 寄存器
      11. 12.2.11 PF Status B 寄存器
      12. 12.2.12 PF Alert C 寄存器
      13. 12.2.13 PF Status C 寄存器
      14. 12.2.14 PF Alert D 寄存器
      15. 12.2.15 PF Status D 寄存器
      16. 12.2.16 电池状态寄存器
      17. 12.2.17 警报状态寄存器
      18. 12.2.18 警报原始状态寄存器
      19. 12.2.19 警报使能寄存器
      20. 12.2.20 FET 状态寄存器
    3. 12.3 仅限命令的子命令
    4. 12.4 带数据的子命令
    5. 12.5 子命令的位字段定义
      1. 12.5.1 PF Status A 寄存器
      2. 12.5.2 PF Status B 寄存器
      3. 12.5.3 PF Status C 寄存器
      4. 12.5.4 PF Status D 寄存器
      5. 12.5.5 制造状态寄存器
      6. 12.5.6 FET 控制寄存器
      7. 12.5.7 REG12 控制寄存器
      8. 12.5.8 OTP 写入检查结果寄存器
      9. 12.5.9 OTP 写入结果寄存器
  14. 13数据存储器设置
    1. 13.1 数据存储器访问
    2. 13.2 校准
      1. 13.2.1  Calibration:Voltage
        1. 13.2.1.1  Calibration:Voltage:Cell 1 Gain
        2. 13.2.1.2  Calibration:Voltage:Cell 2 Gain
        3. 13.2.1.3  Calibration:Voltage:Cell 3 Gain
        4. 13.2.1.4  Calibration:Voltage:Cell 4 Gain
        5. 13.2.1.5  Calibration:Voltage:Cell 5 Gain
        6. 13.2.1.6  Calibration:Voltage:Cell 6 Gain
        7. 13.2.1.7  Calibration:Voltage:Cell 7 Gain
        8. 13.2.1.8  Calibration:Voltage:Cell 8 Gain
        9. 13.2.1.9  Calibration:Voltage:Cell 9 Gain
        10. 13.2.1.10 Calibration:Voltage:Cell 10 Gain
        11. 13.2.1.11 Calibration:Voltage:Cell 11 Gain
        12. 13.2.1.12 Calibration:Voltage:Cell 12 Gain
        13. 13.2.1.13 Calibration:Voltage:Cell 13 Gain
        14. 13.2.1.14 Calibration:Voltage:Cell 14 Gain
        15. 13.2.1.15 Calibration:Voltage:Cell 15 Gain
        16. 13.2.1.16 Calibration:Voltage:Cell 16 Gain
        17. 13.2.1.17 Calibration:Voltage:Pack Gain
        18. 13.2.1.18 Calibration:Voltage:TOS Gain
        19. 13.2.1.19 Calibration:Voltage:LD Gain
        20. 13.2.1.20 Calibration:Voltage:ADC Gain
      2. 13.2.2  Calibration:Current
        1. 13.2.2.1 Calibration:Current:CC Gain
        2. 13.2.2.2 Calibration:Current:Capacity Gain
      3. 13.2.3  Calibration:Vcell Offset
        1. 13.2.3.1 Calibration:Vcell Offset:Vcell Offset
      4. 13.2.4  Calibration:V Divider Offset
        1. 13.2.4.1 Calibration:V Divider Offset:Vdiv Offset
      5. 13.2.5  Calibration:Current Offset
        1. 13.2.5.1 Calibration:Current Offset:Coulomb Counter Offset Samples
        2. 13.2.5.2 Calibration:Current Offset:Board Offset
      6. 13.2.6  Calibration:Temperature
        1. 13.2.6.1  Calibration:Temperature:Internal Temp Offset
        2. 13.2.6.2  Calibration:Temperature:CFETOFF Temp Offset
        3. 13.2.6.3  Calibration:Temperature:DFETOFF Temp Offset
        4. 13.2.6.4  Calibration:Temperature:ALERT Temp Offset
        5. 13.2.6.5  Calibration:Temperature:TS1 Temp Offset
        6. 13.2.6.6  Calibration:Temperature:TS2 Temp Offset
        7. 13.2.6.7  Calibration:Temperature:TS3 Temp Offset
        8. 13.2.6.8  Calibration:Temperature:HDQ Temp Offset
        9. 13.2.6.9  Calibration:Temperature:DCHG Temp Offset
        10. 13.2.6.10 Calibration:Temperature:DDSG Temp Offset
      7. 13.2.7  Calibration:Internal Temp Model
        1. 13.2.7.1 Calibration:Internal Temp Model:Int Gain
        2. 13.2.7.2 Calibration:Internal Temp Model:Int base offset
        3. 13.2.7.3 Calibration:Internal Temp Model:Int Maximum AD
        4. 13.2.7.4 Calibration:Internal Temp Model:Int Maximum Temp
      8. 13.2.8  Calibration:18K Temperature Model
        1. 13.2.8.1  Calibration:18K Temperature Model:Coeff a1
        2. 13.2.8.2  Calibration:18K Temperature Model:Coeff a2
        3. 13.2.8.3  Calibration:18K Temperature Model:Coeff a3
        4. 13.2.8.4  Calibration:18K Temperature Model:Coeff a4
        5. 13.2.8.5  Calibration:18K Temperature Model:Coeff a5
        6. 13.2.8.6  Calibration:18K Temperature Model:Coeff b1
        7. 13.2.8.7  Calibration:18K Temperature Model:Coeff b2
        8. 13.2.8.8  Calibration:18K Temperature Model:Coeff b3
        9. 13.2.8.9  Calibration:18K Temperature Model:Coeff b4
        10. 13.2.8.10 Calibration:18K Temperature Model:Adc0
      9. 13.2.9  Calibration:180K Temperature Model
        1. 13.2.9.1  Calibration:180K Temperature Model:Coeff a1
        2. 13.2.9.2  Calibration:180K Temperature Model:Coeff a2
        3. 13.2.9.3  Calibration:180K Temperature Model:Coeff a3
        4. 13.2.9.4  Calibration:180K Temperature Model:Coeff a4
        5. 13.2.9.5  Calibration:180K Temperature Model:Coeff a5
        6. 13.2.9.6  Calibration:180K Temperature Model:Coeff b1
        7. 13.2.9.7  Calibration:180K Temperature Model:Coeff b2
        8. 13.2.9.8  Calibration:180K Temperature Model:Coeff b3
        9. 13.2.9.9  Calibration:180K Temperature Model:Coeff b4
        10. 13.2.9.10 Calibration:180K Temperature Model:Adc0
      10. 13.2.10 Calibration:Custom Temperature Model
        1. 13.2.10.1  Calibration:Custom Temperature Model:Coeff a1
        2. 13.2.10.2  Calibration:Custom Temperature Model:Coeff a2
        3. 13.2.10.3  Calibration:Custom Temperature Model:Coeff a3
        4. 13.2.10.4  Calibration:Custom Temperature Model:Coeff a4
        5. 13.2.10.5  Calibration:Custom Temperature Model:Coeff a5
        6. 13.2.10.6  Calibration:Custom Temperature Model:Coeff b1
        7. 13.2.10.7  Calibration:Custom Temperature Model:Coeff b2
        8. 13.2.10.8  Calibration:Custom Temperature Model:Coeff b3
        9. 13.2.10.9  Calibration:Custom Temperature Model:Coeff b4
        10. 13.2.10.10 Calibration:Custom Temperature Model:Rc0
        11. 13.2.10.11 Calibration:Custom Temperature Model:Adc0
      11. 13.2.11 Calibration:Current Deadband
        1. 13.2.11.1 Calibration:Current Deadband:Coulomb Counter Deadband
      12. 13.2.12 Calibration:CUV
        1. 13.2.12.1 Calibration:CUV:CUV Threshold Override
      13. 13.2.13 Calibration:COV
        1. 13.2.13.1 Calibration:COV:COV Threshold Override
    3. 13.3 设置
      1. 13.3.1  Settings:Fuse
        1. 13.3.1.1 Settings:Fuse:Min Blow Fuse Voltage
        2. 13.3.1.2 Settings:Fuse:Fuse Blow Timeout
      2. 13.3.2  Settings:Configuration
        1. 13.3.2.1  Settings:Configuration:Power Config
        2. 13.3.2.2  Settings:Configuration:REG12 Config
        3. 13.3.2.3  Settings:Configuration:REG0 Config
        4. 13.3.2.4  Settings:Configuration:HWD Regulator Options
        5. 13.3.2.5  Settings:Configuration:Comm Type
        6. 13.3.2.6  Settings:Configuration:I2C Address
        7. 13.3.2.7  Settings:Configuration:SPI Configuration
        8. 13.3.2.8  Settings:Configuration:Comm Idle Time
        9. 13.3.2.9  Settings:Configuration:CFETOFF Pin Config
        10. 13.3.2.10 Settings:Configuration:DFETOFF Pin Config
        11. 13.3.2.11 Settings:Configuration:ALERT Pin Config
        12. 13.3.2.12 Settings:Configuration:TS1 Config
        13. 13.3.2.13 Settings:Configuration:TS2 Config
        14. 13.3.2.14 Settings:Configuration:TS3 Config
        15. 13.3.2.15 Settings:Configuration:HDQ Pin Config
        16. 13.3.2.16 Settings:Configuration:DCHG Pin Config
        17. 13.3.2.17 Settings:Configuration:DDSG Pin Config
        18. 13.3.2.18 Settings:Configuration:DA Configuration
        19. 13.3.2.19 Settings:Configuration:Vcell Mode
        20. 13.3.2.20 Settings:Configuration:CC3 Samples
      3. 13.3.3  Settings:Protection
        1. 13.3.3.1  Settings:Protection:Protection Configuration
        2. 13.3.3.2  Settings:Protection:Enabled Protections A
        3. 13.3.3.3  Settings:Protection:Enabled Protections B
        4. 13.3.3.4  Settings:Protection:Enabled Protections C
        5. 13.3.3.5  Settings:Protection:CHG FET Protections A
        6. 13.3.3.6  Settings:Protection:CHG FET Protections B
        7. 13.3.3.7  Settings:Protection:CHG FET Protections C
        8. 13.3.3.8  Settings:Protection:DSG FET Protections A
        9. 13.3.3.9  Settings:Protection:DSG FET Protections B
        10. 13.3.3.10 Settings:Protection:DSG FET Protections C
        11. 13.3.3.11 Settings:Protection:Body Diode Threshold
      4. 13.3.4  Settings:Alarm
        1. 13.3.4.1 Settings:Alarm:Default Alarm Mask
        2. 13.3.4.2 Settings:Alarm:SF Alert Mask A
        3. 13.3.4.3 Settings:Alarm:SF Alert Mask B
        4. 13.3.4.4 Settings:Alarm:SF Alert Mask C
        5. 13.3.4.5 Settings:Alarm:PF Alert Mask A
        6. 13.3.4.6 Settings:Alarm:PF Alert Mask B
        7. 13.3.4.7 Settings:Alarm:PF Alert Mask C
        8. 13.3.4.8 Settings:Alarm:PF Alert Mask D
      5. 13.3.5  Settings:Permanent Failure
        1. 13.3.5.1 Settings:Permanent Failure:Enabled PF A
        2. 13.3.5.2 Settings:Permanent Failure:Enabled PF B
        3. 13.3.5.3 Settings:Permanent Failure:Enabled PF C
        4. 13.3.5.4 Settings:Permanent Failure:Enabled PF D
      6. 13.3.6  Settings:FET
        1. 13.3.6.1 Settings:FET:FET Options
        2. 13.3.6.2 Settings:FET:Chg Pump Control
        3. 13.3.6.3 Settings:FET:Precharge Start Voltage
        4. 13.3.6.4 Settings:FET:Precharge Stop Voltage
        5. 13.3.6.5 Settings:FET:Predischarge Timeout
        6. 13.3.6.6 Settings:FET:Predischarge Stop Delta
      7. 13.3.7  Settings:Current Thresholds
        1. 13.3.7.1 Settings:Current Thresholds:Dsg Current Threshold
        2. 13.3.7.2 Settings:Current Thresholds:Chg Current Threshold
      8. 13.3.8  Settings:Cell Open-Wire
        1. 13.3.8.1 Settings:Cell Open-Wire:Check Time
      9. 13.3.9  Settings:Interconnect Resistances
        1. 13.3.9.1  Settings:Interconnect Resistances:Cell 1 Interconnect
        2. 13.3.9.2  Settings:Interconnect Resistances:Cell 2 Interconnect
        3. 13.3.9.3  Settings:Interconnect Resistances:Cell 3 Interconnect
        4. 13.3.9.4  Settings:Interconnect Resistances:Cell 4 Interconnect
        5. 13.3.9.5  Settings:Interconnect Resistances:Cell 5 Interconnect
        6. 13.3.9.6  Settings:Interconnect Resistances:Cell 6 Interconnect
        7. 13.3.9.7  Settings:Interconnect Resistances:Cell 7 Interconnect
        8. 13.3.9.8  Settings:Interconnect Resistances:Cell 8 Interconnect
        9. 13.3.9.9  Settings:Interconnect Resistances:Cell 9 Interconnect
        10. 13.3.9.10 Settings:Interconnect Resistances:Cell 10 Interconnect
        11. 13.3.9.11 Settings:Interconnect Resistances:Cell 11 Interconnect
        12. 13.3.9.12 Settings:Interconnect Resistances:Cell 12 Interconnect
        13. 13.3.9.13 Settings:Interconnect Resistances:Cell 13 Interconnect
        14. 13.3.9.14 Settings:Interconnect Resistances:Cell 14 Interconnect
        15. 13.3.9.15 Settings:Interconnect Resistances:Cell 15 Interconnect
        16. 13.3.9.16 Settings:Interconnect Resistances:Cell 16 Interconnect
      10. 13.3.10 Settings:Manufacturing
        1. 13.3.10.1 Settings:Manufacturing:Mfg Status Init
      11. 13.3.11 Settings:Cell Balancing Config
        1. 13.3.11.1  Settings:Cell Balancing Config:Balancing Configuration
        2. 13.3.11.2  Settings:Cell Balancing Config:Min Cell Temp
        3. 13.3.11.3  Settings:Cell Balancing Config:Max Cell Temp
        4. 13.3.11.4  Settings:Cell Balancing Config:Max Internal Temp
        5. 13.3.11.5  Settings:Cell Balancing Config:Cell Balance Interval
        6. 13.3.11.6  Settings:Cell Balancing Config:Cell Balance Max Cells
        7. 13.3.11.7  Settings:Cell Balancing Config:Cell Balance Min Cell V (Charge)
        8. 13.3.11.8  Settings:Cell Balancing Config:Cell Balance Min Delta (Charge)
        9. 13.3.11.9  Settings:Cell Balancing Config:Cell Balance Stop Delta (Charge)
        10. 13.3.11.10 Settings:Cell Balancing Config:Cell Balance Min Cell V (Relax)
        11. 13.3.11.11 Settings:Cell Balancing Config:Cell Balance Min Delta (Relax)
        12. 13.3.11.12 Settings:Cell Balancing Config:Cell Balance Stop Delta (Relax)
    4. 13.4 功率
      1. 13.4.1 Power:Shutdown
        1. 13.4.1.1 Power:Shutdown:Shutdown Cell Voltage
        2. 13.4.1.2 Power:Shutdown:Shutdown Stack Voltage
        3. 13.4.1.3 Power:Shutdown:Low V Shutdown Delay
        4. 13.4.1.4 Power:Shutdown:Shutdown Temperature
        5. 13.4.1.5 Power:Shutdown:Shutdown Temperature Delay
        6. 13.4.1.6 Power:Shutdown:FET Off Delay
        7. 13.4.1.7 Power:Shutdown:Shutdown Command Delay
        8. 13.4.1.8 Power:Shutdown:Auto Shutdown Time
        9. 13.4.1.9 Power:Shutdown:RAM Fail Shutdown Time
      2. 13.4.2 Power:Sleep
        1. 13.4.2.1 Power:Sleep:Sleep Current
        2. 13.4.2.2 Power:Sleep:Voltage Time
        3. 13.4.2.3 Power:Sleep:Wake Comparator Current
        4. 13.4.2.4 Power:Sleep:Sleep Hysteresis Time
        5. 13.4.2.5 Power:Sleep:Sleep Charger Voltage Threshold
        6. 13.4.2.6 Power:Sleep:Sleep Charger PACK-TOS Delta
    5. 13.5 系统数据
      1. 13.5.1 System Data:Integrity
        1. 13.5.1.1 System Data:Integrity:Config RAM Signature
    6. 13.6 保护功能
      1. 13.6.1  Protections:CUV
        1. 13.6.1.1 Protections:CUV:Threshold
        2. 13.6.1.2 Protections:CUV:Delay
        3. 13.6.1.3 Protections:CUV:Recovery Hysteresis
      2. 13.6.2  Protections:COV
        1. 13.6.2.1 Protections:COV:Threshold
        2. 13.6.2.2 Protections:COV:Delay
        3. 13.6.2.3 Protections:COV:Recovery Hysteresis
      3. 13.6.3  Protections:COVL
        1. 13.6.3.1 Protections:COVL:Latch Limit
        2. 13.6.3.2 Protections:COVL:Counter Dec Delay
        3. 13.6.3.3 Protections:COVL:Recovery Time
      4. 13.6.4  Protections:OCC
        1. 13.6.4.1 Protections:OCC:Threshold
        2. 13.6.4.2 Protections:OCC:Delay
        3. 13.6.4.3 Protections:OCC:Recovery Threshold
        4. 13.6.4.4 Protections:OCC:PACK-TOS Delta
      5. 13.6.5  Protections:OCD1
        1. 13.6.5.1 Protections:OCD1:Threshold
        2. 13.6.5.2 Protections:OCD1:Delay
      6. 13.6.6  Protections:OCD2
        1. 13.6.6.1 Protections:OCD2:Threshold
        2. 13.6.6.2 Protections:OCD2:Delay
      7. 13.6.7  Protections:SCD
        1. 13.6.7.1 Protections:SCD:Threshold
        2. 13.6.7.2 Protections:SCD:Delay
        3. 13.6.7.3 Protections:SCD:Recovery Time
      8. 13.6.8  Protections:OCD3
        1. 13.6.8.1 Protections:OCD3:Threshold
        2. 13.6.8.2 Protections:OCD3:Delay
      9. 13.6.9  Protections:OCD
        1. 13.6.9.1 Protections:OCD:Recovery Threshold
      10. 13.6.10 Protections:OCDL
        1. 13.6.10.1 Protections:OCDL:Latch Limit
        2. 13.6.10.2 Protections:OCDL:Counter Dec Delay
        3. 13.6.10.3 Protections:OCDL:Recovery Time
        4. 13.6.10.4 Protections:OCDL:Recovery Threshold
      11. 13.6.11 Protections:SCDL
        1. 13.6.11.1 Protections:SCDL:Latch Limit
        2. 13.6.11.2 Protections:SCDL:Counter Dec Delay
        3. 13.6.11.3 Protections:SCDL:Recovery Time
        4. 13.6.11.4 Protections:SCDL:Recovery Threshold
      12. 13.6.12 Protections:OTC
        1. 13.6.12.1 Protections:OTC:Threshold
        2. 13.6.12.2 Protections:OTC:Delay
        3. 13.6.12.3 Protections:OTC:Recovery
      13. 13.6.13 Protections:OTD
        1. 13.6.13.1 Protections:OTD:Threshold
        2. 13.6.13.2 Protections:OTD:Delay
        3. 13.6.13.3 Protections:OTD:Recovery
      14. 13.6.14 Protections:OTF
        1. 13.6.14.1 Protections:OTF:Threshold
        2. 13.6.14.2 Protections:OTF:Delay
        3. 13.6.14.3 Protections:OTF:Recovery
      15. 13.6.15 Protections:OTINT
        1. 13.6.15.1 Protections:OTINT:Threshold
        2. 13.6.15.2 Protections:OTINT:Delay
        3. 13.6.15.3 Protections:OTINT:Recovery
      16. 13.6.16 Protections:UTC
        1. 13.6.16.1 Protections:UTC:Threshold
        2. 13.6.16.2 Protections:UTC:Delay
        3. 13.6.16.3 Protections:UTC:Recovery
      17. 13.6.17 Protections:UTD
        1. 13.6.17.1 Protections:UTD:Threshold
        2. 13.6.17.2 Protections:UTD:Delay
        3. 13.6.17.3 Protections:UTD:Recovery
      18. 13.6.18 Protections:UTINT
        1. 13.6.18.1 Protections:UTINT:Threshold
        2. 13.6.18.2 Protections:UTINT:Delay
        3. 13.6.18.3 Protections:UTINT:Recovery
      19. 13.6.19 Protections:Recovery
        1. 13.6.19.1 Protections:Recovery:Time
      20. 13.6.20 Protections:HWD
        1. 13.6.20.1 Protections:HWD:Delay
      21. 13.6.21 Protections:Load Detect
        1. 13.6.21.1 Protections:Load Detect:Active Time
        2. 13.6.21.2 Protections:Load Detect:Retry Delay
        3. 13.6.21.3 Protections:Load Detect:Timeout
      22. 13.6.22 Protections:PTO
        1. 13.6.22.1 Protections:PTO:Charge Threshold
        2. 13.6.22.2 Protections:PTO:Delay
        3. 13.6.22.3 Protections:PTO:Reset
    7. 13.7 Permanent Fail
      1. 13.7.1  Permanent Fail:CUDEP
        1. 13.7.1.1 Permanent Fail:CUDEP:Threshold
        2. 13.7.1.2 Permanent Fail:CUDEP:Delay
      2. 13.7.2  Permanent Fail:SUV
        1. 13.7.2.1 Permanent Fail:SUV:Threshold
        2. 13.7.2.2 Permanent Fail:SUV:Delay
      3. 13.7.3  Permanent Fail:SOV
        1. 13.7.3.1 Permanent Fail:SOV:Threshold
        2. 13.7.3.2 Permanent Fail:SOV:Delay
      4. 13.7.4  Permanent Fail:TOS
        1. 13.7.4.1 Permanent Fail:TOS:Threshold
        2. 13.7.4.2 Permanent Fail:TOS:Delay
      5. 13.7.5  Permanent Fail:SOCC
        1. 13.7.5.1 Permanent Fail:SOCC:Threshold
        2. 13.7.5.2 Permanent Fail:SOCC:Delay
      6. 13.7.6  Permanent Fail:SOCD
        1. 13.7.6.1 Permanent Fail:SOCD:Threshold
        2. 13.7.6.2 Permanent Fail:SOCD:Delay
      7. 13.7.7  Permanent Fail:SOT
        1. 13.7.7.1 Permanent Fail:SOT:Threshold
        2. 13.7.7.2 Permanent Fail:SOT:Delay
      8. 13.7.8  Permanent Fail:SOTF
        1. 13.7.8.1 Permanent Fail:SOTF:Threshold
        2. 13.7.8.2 Permanent Fail:SOTF:Delay
      9. 13.7.9  Permanent Fail:VIMR
        1. 13.7.9.1 Permanent Fail:VIMR:Check Voltage
        2. 13.7.9.2 Permanent Fail:VIMR:Max Relax Current
        3. 13.7.9.3 Permanent Fail:VIMR:Threshold
        4. 13.7.9.4 Permanent Fail:VIMR:Delay
        5. 13.7.9.5 Permanent Fail:VIMR:Relax Min Duration
      10. 13.7.10 Permanent Fail:VIMA
        1. 13.7.10.1 Permanent Fail:VIMA:Check Voltage
        2. 13.7.10.2 Permanent Fail:VIMA:Min Active Current
        3. 13.7.10.3 Permanent Fail:VIMA:Threshold
        4. 13.7.10.4 Permanent Fail:VIMA:Delay
      11. 13.7.11 Permanent Fail:CFETF
        1. 13.7.11.1 Permanent Fail:CFETF:OFF Threshold
        2. 13.7.11.2 Permanent Fail:CFETF:OFF Delay
      12. 13.7.12 Permanent Fail:DFETF
        1. 13.7.12.1 Permanent Fail:DFETF:OFF Threshold
        2. 13.7.12.2 Permanent Fail:DFETF:OFF Delay
      13. 13.7.13 Permanent Fail:VSSF
        1. 13.7.13.1 Permanent Fail:VSSF:Fail Threshold
        2. 13.7.13.2 Permanent Fail:VSSF:Delay
      14. 13.7.14 Permanent Fail:2LVL
        1. 13.7.14.1 Permanent Fail:2LVL:Delay
      15. 13.7.15 Permanent Fail:LFOF
        1. 13.7.15.1 Permanent Fail:LFOF:Delay
      16. 13.7.16 Permanent Fail:HWMX
        1. 13.7.16.1 Permanent Fail:HWMX:Delay
    8. 13.8 安全性
      1. 13.8.1 Security:Settings
        1. 13.8.1.1 Security:Settings:Security Settings
      2. 13.8.2 Security:Keys
        1. 13.8.2.1 Security:Keys:Unseal Key Step 1
        2. 13.8.2.2 Security:Keys:Unseal Key Step 2
        3. 13.8.2.3 Security:Keys:Full Access Key Step 1
        4. 13.8.2.4 Security:Keys:Full Access Key Step 2
    9. 13.9 数据存储器汇总
  15. 15修订历史记录

I2C 通信子系统

BQ76952 器件中的 I2C 串行通信接口用作响应器件,支持高达 400kHz 的速率和可选的 CRC 检查。如果尚未对 OTP 进行编程,则 BQ76952 将默认在 400kHz I2C 模式初始上电,而其他版本的器件可能具有不同的默认设置(例如,BQ7695201 将默认在带 CRC 模式的 SPI 中初始上电)。可以在生产线上对 OTP 设置进行编程,然后当该器件上电时,根据 OTP 设置自动进入所选模式。在 CONFIG_UPDATE 模式下,主机也可以更改 I2C 速度设置,然后新的速度设置将在退出 CONFIG_UPDATE 模式时生效。或者,主机可以写入 0x29e7 SWAP_TO_I2C() 子命令,以立即将通信接口更改为 I2C 快速模式 (Settings:Configuration:Comm Type = 8),而无需进入 CONFIG_UPDATE 模式。可以发送 0x29BC SWAP_COMM_MODE() 子命令,以将器件转换至 Settings:Configuration:Comm Type 中的设置选择的通信模式。

I2C 器件地址默认设置为 0x10(写入)、0x11(读取),可以通过使用所需的写入地址对 Settings:Configuration:I2C Address 进行编程来更改该地址。

通信接口包含可选的超时功能,可以根据 Comm Type 设置启用该功能。仅当总线将以 100kHz 或 400kHz 的频率运行时,才应使用具有超时功能的 Comm Type 设置。当 Comm Type= 0x1E(启用超时的 100kHz 模式)时,如果检测到时钟为低电平超过 tTIMEOUT(25ms 至 35ms),或者累积的时钟低电平响应器延长时间超过约 25ms,或者如果累积的时钟低电平控制器延长时间超过 10ms,则器件将重置通信接口逻辑。当 Comm Type = 0x09(启用超时的 400kHz 模式)时,如果检测到时钟为低电平超过 tTIMEOUT(5ms 至 20ms),则器件将重置通信接口逻辑。如果检测到 SCL 引脚为低电平超过 2 秒,则总线还包括一个长期超时,无论 Comm Type 设置是否包含超时都是如此。

I2C 写入事务如 图 10-1 所示。通过在停止之前发送额外的数据字节来允许进行块写入。I2C 逻辑将在每个数据字节后自动递增寄存器地址。

启用时,可以通过以下方式来计算 CRC:

  • 在单字节写入事务中,根据响应器地址、寄存器地址和数据来计算 CRC。
  • 在块写入事务中,根据响应器地址、寄存器地址和数据来计算第一个数据字节的 CRC。后续数据字节的 CRC仅根据数据字节来计算。

CRC 多项式为 x8 + x2 + x + 1,初始值为 0。

当响应器检测到错误的 CRC 时,I2C 响应器将不确认 CRC,从而使 I2C 响应器进入空闲状态。



图 9-1 I2C 写入

图 10-2 显示了一个使用重复启动的读取事务。



图 9-2 使用重复启动的 I2C 读取

图 10-3 显示了一个未使用重复启动的读取事务(例如在硬件中不可用时)。对于块读取,控制器确认除最后一个数据字节之外的每个数据字节,并继续为接口提供时钟。I2C 块将在每个数据字节后自动递增寄存器地址。

启用时,可以通过以下方式来计算读取事务的 CRC:

  • 在单字节读取事务中,CRC 是从第一个启动开始计算的,因此将包含响应器地址、寄存器地址、然后是设置了读取位的响应器地址,再是数据字节。
  • 在块读取事务中,第一个数据字节的CRC 是从第一个启动开始计算的,将包含响应器地址、寄存器地址、然后是设置了读取位的响应器地址,再是数据字节。CRC 在每个数据字节后和每次停止后都会复位。后续数据字节的 CRC仅根据数据字节来计算。

CRC 多项式为 x8 + x2 + x + 1,初始值为 0。

当控制器检测到错误的 CRC 时,I2C 控制器将不确认 CRC,从而使 I2C 响应器进入空闲状态。



图 9-3 不使用重复启动的 I2C 读取

当主机发送读取事务时,该器件在获取数据并准备发送数据时可能会发生时钟延长。不过,当发送的子命令需要该器件获取数据并将其加载到 0x40 – 0x5F 传输缓冲区时,该器件在此期间不会发生时钟延长。器件获取数据所需的时间取决于特定的子命令和器件内正在进行的任何其他处理,因此在运行期间会有所不同。表 10-2描述了该器件获取子命令数据所需的大致时间。发送子命令时,建议等待足够长的时间以使该器件获取数据,然后再次读取 0x3E/0x3F。如果从该读取中回显初始子命令,则获取的数据可用并且可以从传输缓冲区中读取。
