Design Above a Minimum Current Limit

Some applications require that current limiting cannot occur below a certain threshold. For this example, assume that 2.1 A must be delivered to the load so that the minimum desired current-limit threshold is 2100 mA. Use the IOS equations (Equation 1) and Figure 9-4 to select RILIM as shown in Equation 2.

Equation 2. GUID-C84A0EC4-071C-42A3-874B-FE25FB29F7FE-low.gif

Select the closest 1% resistor less than the calculated value: RILIM = 42.2 kΩ. This sets the minimum current-limit threshold at 2130 mA as shown in Equation 3.

Equation 3. GUID-5623BEA2-DA45-4AA0-BCF9-F272718DEB9B-low.gif

Use the IOS equations (Equation 1), Figure 9-4, and the previously calculated value for RILIM to calculate the maximum resulting current-limit threshold as shown in Equation 4.

Equation 4. GUID-B0E00628-A75B-4714-8A6E-8208459FB957-low.gif

The resulting current-limit threshold minimum is 2130 mA and maximum is 2479 mA with RILIM = 42.2kΩ ± 1%.
