6.7 Typical Characteristics

Table 1. Table Of Graphs

See Figure 18
TITLE TEST CONDITIONS FIGURE
Dimming Linearity 24 LEDs (VOUT = 80 V), VIN = 24 V Figure 1
Dimming Linearity at Small Dimming Duty Cycle 24 LEDs (VOUT = 80 V), VIN = 24 V Figure 2
DC Load Efficiency fSW = 130 kHz Figure 3
Switching Frequency Setting VIN = 24 V Figure 4
Boost Switching Waveform VIN = 24 V, VOUT = 80 V, IOUT = 300 mA Figure 5
Dimming Waveform (2% Dimming) VIN = 24 V, VOUT = 80 V, IOUT = 300 mA, 100-Hz dimming frequency Figure 6
Startup Waveform (1% Dimming) 100-Hz dimming frequency, 1% dimming duty cycle Figure 7
Startup Waveform (100% Dimming) 100-Hz dimming frequency, 100% dimming duty cycle Figure 8
Shutdown Waveform (1% Dimming) 100-Hz dimming frequency, 1% dimming duty cycle Figure 9
Shutdown Waveform (100% Dimming) 100-Hz dimming frequenc, 100% dimming duty cycle Figure 10
LED Open Protection (1% Dimming) 100-Hz dimming frequenc, 1% dimming duty cycle Figure 11
LED Open Protection (100% Dimming) 100-Hz dimming frequenc, 100% Dimming Duty Cycle Figure 12
LED String Short Protection (1% Dimming) 100-Hz dimming frequency, 1% dimming duty cycle Figure 13
LED String Short Protection (100% Dimming) 100-Hz dimming frequency, 1% dimming duty cycle Figure 14
TPS61197 C003_SLVSC25.png
Figure 1. Dimming Linearity
TPS61197 C005_SLVSC25.png
Figure 3. DC Load Efficiency
TPS61197 C004_SLVSC25.png
Figure 2. Dimming Linearity at Low Dimming Duty Cycle
TPS61197 C006_SLVSC25.png
Figure 4. Switching Frequency Setting
TPS61197 S1_lvsc25.gif
Figure 5. Boost Switching Waveform
TPS61197 S3_lvsc25.gif
Figure 7. Start-up Waveform (1% Dimming)
TPS61197 S5_lvsc25.gif
Figure 9. Shutdown Waveform (1% Dimming)
TPS61197 S7_lvsc25.gif
Figure 11. LED Open Protection (1% Dimming)
TPS61197 S9_lvsc25.gif
Figure 13. LED String Short Protection (1% Dimming)
TPS61197 S2_lvsc25.gif
Figure 6. Dimming Waveform (1% Dimming)
TPS61197 S4_lvsc25.gif
Figure 8. Start-up Waveform (100% Dimming)
TPS61197 S6_lvsc25.gif
Figure 10. Shutdown Waveform (100% Dimming)
TPS61197 S8_lvsc25.gif
Figure 12. LED Open Protection (100% Dimming)
TPS61197 S10_lvsc25.gif
Figure 14. LED String Short Protection (100% Dimming)
