多轴线性和角度位置传感器

用于 3D 位置跟踪和物体角度位置检测的高精度、低功耗、多功能 3D 霍尔效应传感器

parametric-filter查看所有产品
我们的多轴线性和角度位置传感器采用霍尔效应和 AMR 等技术以及 SPI、I2C 和正弦/余弦等接口,并且具有功能安全、超高精度、内置 CORDIC 和低功耗等特性,可提高系统质量。无论您是希望跟踪物体的线性位移,还是要获得精确的角度位置信息,我们的多轴线性和角度位置传感器都能提供具有机械灵活性和诊断功能的可配置解决方案,从而实现可靠的系统运行来满足您的系统需求。

按类别浏览

按类型选择

特色多轴线性和角度位置传感器

为什么选择我们的线性 3D 霍尔效应传感器?

checkmark

集成

通过高度集成板载补偿、诊断和角度计算,可简化系统设计,这样无需片外处理,同时提供了机械放置灵活性。

checkmark

精度

在高达 20ksps 的速度下无需校准即可实现超高精度,便于进行更快速、更精确的实时控制。

checkmark

低功耗

可对带宽选项进行配置,平均电流消耗低至 1μA,这样,系统功耗和性能得以优化。

我们多轴线性和角度位置传感器的优势

高级跟踪功能可改善系统控制和同步

优势:

  • 可靠的定位,可实现一致的系统控制。
  • 降低对系统、附近物体或人员造成损坏或伤害的风险。
  • 改进功能的同步和时序控制,可实现更快的响应。
  • 在各种运动范围内进行位置跟踪。
  • 多个灵敏度轴可实现篡改和杂散磁场检测。
  • 可灵活放置。
  • 能够通过数字接口将数据发送回微控制器。
Video Player is loading.
Current Time 0:00
Duration 7:20
Loaded: 2.26%
Stream Type LIVE
Remaining Time 7:20

1x
  • Chapters
  • descriptions off, selected
  • subtitles off, selected
  • en (Main), selected
应用简报
使用绝对位置传感器测量 3D 运动 (Rev. B)
了解如何使用绝对位置传感器测量三维运动。
PDF | HTML
应用简报
3D 霍尔效应传感器在机器人设计中的机械优势 (Rev. A)
了解在机器人设计中使用 3D 霍尔效应传感器的机械优势。
PDF | HTML
应用手册
3D Hall-Effect Sensor for Knobs in Appliances.
了解如何将 3D 霍尔效应传感器用于电器中的旋钮应用。
PDF | HTML
实现3D的特色产品
TMAG3001 正在供货 采用 Wafer Chip-Scale Package、具有 I²C 和可编程开关的三轴线性霍尔效应传感器
TMAG5273 正在供货 具有 I²C 接口的低功耗线性 3D 霍尔效应传感器
TMAG5170 正在供货 具有串行外设接口的高精度线性 3D 霍尔效应传感器

技术资源

技术文章
技术文章
How 3D Hall-effect sensors deliver precise, real-time position control to autonomo
了解 TMAG5170 如何在自动化工业系统中实现增强的实时控制和诊断功能。
document-pdfAcrobat PDF
白皮书
白皮书
使用线性 3D 霍尔效应位置传感器提升系统性能
了解如何借助线性 3D 霍尔效应传感器,确保在需要绝对位置测量的应用中实现系统级精度和可靠性。
document-pdfAcrobat PDF
视频系列
视频系列
TI 高精度实验室 - 磁传感器视频系列
观看我们有关磁传感器的 TI 高精度实验室视频,了解如何使用线性 3D 霍尔效应传感器进行设计。

了解特色应用

电器
Optimize performance, size and cost with multiaxis linear and angle position sensors for appliance designs
楼宇自动化
Gain high performance while optimizing cost and space with multiaxis linear and angle sensors in building automation designs
3D 和角度测量传感
Explore our wide portfolio of multiaxis linear and angle position sensors for automotive and industrial applications

Optimize performance, size and cost with multiaxis linear and angle position sensors for appliance designs

You can use multiaxis linear and angle position sensors for bump detection, liquid level sensing, knob or dial selection, and wheel speed and direction tracking in end equipment such as vacuum robots, washers and dryers, cooktops, ovens, and robotic lawn mowers.

Benefits:

  • Fast, accurate and precise angle calculation with a built-in coordinate rotation digital computer.
  • Reduce system size and cost by using only one sensor for angle sensing.
  • Gain 360-degree angular position information for both on-and off-axis angle measurement.
  • Multiple axes of sensitivity and placement flexibility.

特色资源

产品
  • TMAG5273 – 具有 I²C 接口的低功耗线性 3D 霍尔效应传感器
  • TMAG3001 – 采用 Wafer Chip-Scale Package、具有 I²C 和可编程开关的三轴线性霍尔效应传感器
硬件开发
  • TMAG5273EVM – TMAG5273 I²C 接口、低功耗线性 3D 霍尔效应传感器评估模块
设计工具和仿真

Gain high performance while optimizing cost and space with multiaxis linear and angle sensors in building automation designs

In building automation, multiaxis linear and angle position sensors can be used for tamper detection and absolute position sensing in end equipment such as electronic smart locks, door and window sensors, and wireless security cameras.

Benefits:

  • Fast, accurate and precise angle calculation with a built-in coordinate rotation digital computer.
  • Reduce system size and cost by using only one sensor for angle sensing.
  • Can determine the strength and proximity of external magnetic fields in regards to tamper detection.
  • Conserve power with a sleep mode current as low as 5nA.

特色资源

产品
  • TMAG5273 – 具有 I²C 接口的低功耗线性 3D 霍尔效应传感器
  • TMAG5170 – 具有串行外设接口的高精度线性 3D 霍尔效应传感器
  • TMAG3001 – 采用 Wafer Chip-Scale Package、具有 I²C 和可编程开关的三轴线性霍尔效应传感器
硬件开发
  • TMAG5273EVM – TMAG5273 I²C 接口、低功耗线性 3D 霍尔效应传感器评估模块
  • TMAG3001EVM – TMAG3001 具有 I²C 和可编程开关的三轴线性霍尔效应传感器评估模块
设计工具和仿真

Explore our wide portfolio of multiaxis linear and angle position sensors for automotive and industrial applications

Magnetic position sensors for automotive and industrial applications enable precise linear displacement and high-accuracy angle measurements.

Benefits:

  • Enable 3D tamper detection for e-meters, door and window sensors, and other end products.
  • 3D sensor availability in wafer chip-scale packages for portable electronics or space-constrained applications.
  • High-accuracy angle sensing (as low as 0.1 degrees at room temperature) leverages Hall-effect and anisotropic magnetoresistive technologies with high-speed or low noise configurations.

特色资源

参考设计
  • TIDA-060045 – 具有精确、低延迟线性位置检测的四通道 3D 霍尔效应传感器参考设计
  • TIDA-060039 – 电感触控和磁旋钮非接触式用户接口参考设计
产品
  • TMAG6181-Q1 – 具有集成匝数计数器的汽车级高精度模拟 AMR 角度传感器
  • TMAG3001 – 采用 Wafer Chip-Scale Package、具有 I²C 和可编程开关的三轴线性霍尔效应传感器
  • TMAG5173-Q1 – 具有 I²C 接口的汽车级高精度、线性 3D 霍尔效应传感器
硬件开发
  • TMAG3001EVM – TMAG3001 具有 I²C 和可编程开关的三轴线性霍尔效应传感器评估模块
  • TMAG6180-6181EVM – 具有差分正弦和余弦模拟输出的 TMAG6180 和 TMAG6181 评估模块
