9.3.2 USB 3.1 and 2 Lanes of DisplayPort

The TUSB1064 operates in USB3.1 and 2 Lanes of DisplayPort mode when the CTL1 pin is high and CTL0 pin is high.

TUSB1064 TUSB1064_DCI_USB31_Plus2_LaneDP_NoFlip.gifFigure 33. USB3.1 + 2 Lane DP – No Flip (CTL1 = H, CTL0 = H, FLIP = L)
TUSB1064 TUSB1064_DCI_USB31_Plus2_LaneDP_Flip.gifFigure 34. USB 3.1 + 2 Lane DP – Flip (CTL1 = H, CTL0 = H, FLIP = H)
