2.3 Thermal Images

Figure 2-3 and Figure 2-4 show the thermal images, captured with forced-air cooling in 25ºC ambient, after 15-minutes operation.

PMP41037 Thermal Image 800VIN, With 84A Load Figure 2-3 Thermal Image 800VIN, With 84A Load
PMP41037 Thermal Image 8VIN, With 1.4A Load Figure 2-4 Thermal Image 8VIN, With 1.4A Load
