7.8 Typical Characteristics

TPS25741 TPS25741A D004_SLVSDG8.gif
IDSCG = 100 mA
Figure 7. VDSCG when VPWR > 4.65 V
TPS25741 TPS25741A D009_SLVSDJ5.gif
CC pins are open
Figure 9. Supply Current when VPWR = 5 V
TPS25741 TPS25741A D008_SLVSDG8.gif
Figure 11. VFOVP While Supplying 9 V, TPS25741A
TPS25741 TPS25741A D010_SLVSDG8.gif
Figure 13. VFOVP While Supplying 15 V, TPS25741A
TPS25741 TPS25741A D016_SLVSDG8.gif
5 A enabled
Figure 15. VITRIP When VPWR> 4.65 V
TPS25741 TPS25741A D012_SLVSDG8.gif
Sink attached at time 0
UFP pulled up to DVDD
Figure 17. DVDD and UFP Upon Sink Attachment
TPS25741 TPS25741A D020_SLVSDJ5.gif
VDD = 5 V
Figure 19. VBUS, CC1, and CC2 Upon Attachment
TPS25741 TPS25741A D005_SLVSDG8.gif
VDSCG = 4 V pulsed testing
Figure 8. IDSCG when VPWR> 4.65 V
TPS25741 TPS25741A D007_SLVSDG8.gif
Figure 10. VFOVP While Supplying 5 V
TPS25741 TPS25741A D009_SLVSDG8.gif
Figure 12. VFOVP While Supplying 12 V, TPS25741
TPS25741 TPS25741A D015_SLVSDG8.gif
Figure 14. VFOVP While Supplying 20 V, TPS25741
TPS25741 TPS25741A D011_SLVSDG8.gif
3 A enabled
Figure 16. VITRIP When VPWR> 4.65 V
TPS25741 TPS25741A D013_SLVSDG8.gif
Sink detached at time 0.19s
Sleep mode entered at time 0.39s.
UFP pulled up to DVDD
Figure 18. DVDD and UFP Upon Sink Attachment
