8.9.2.1.3.4.1 ADC Power-Up Delays
PARAMETER(1)MINMAXUNIT
td(PWD)Delay time for the ADC to be stable after power up1ms
(1) Timings maintain compatibility to the ADC module. The 2806x ADC supports driving all 3 bits at the same time td(PWD) ms before first conversion.
GUID-326A19E4-664B-49D7-9828-F217D53D7C98-low.gifFigure 8-23 ADC Conversion Timing
GUID-47FE8892-1430-4616-AA84-92D2460A614A-low.gifFigure 8-24 ADC Input Impedance Model
