7.8 Typical Characteristics

Unless otherwise specified the following conditions apply: VIN = 12 V, TA = 25°C. Specified temperatures are ambient.

VIN = 12 V
Figure 7-1 Reference Voltage Drift
VIN = 12 V
Figure 7-3 High Side/Peak Current Limit for LM53625/35-Q1
VIN = 12 V
Figure 7-5 Short Circuit Average Input Current for LM53635-Q1
GUID-4D86450E-BE6D-42A9-AE3A-33804E4BB19F-low.gifFigure 7-7 RESET Threshold Fixed 5-V output
VIN = 12 V
Figure 7-2 Switching Frequency vs Temperature
VIN = 12V
Figure 7-4 Low Side/Valley Current Limit for LM53625/35-Q1
VIN = 12 V
Figure 7-6 Shutdown Current
GUID-83053D91-BC7C-4B91-B28F-3A08A800CE47-low.gifFigure 7-8 RESET Threshold as Percentage of Output Voltage
