8.2.2.2.3 Selection of Inductors L1 and L2

Proper selection of inductors L1 and L2 to maintain continuous current conduction mode requires calculations of the following parameters.

Average current in the inductors can be calculated using Equation 39.

Equation 39. LM3478 10135571.png
Equation 40. IL2AVE = IOUT

Peak to peak ripple current, to calculate core loss if necessary using Equation 41 and Equation 42.

Equation 41. LM3478 10135576.png
Equation 42. LM3478 10135577.png

Maintaining the condition IL > ΔiL/2 to ensure continuous current conduction yields Equation 43 and Equation 44.

Equation 43. LM3478 10135572.gif
Equation 44. LM3478 10135573.gif

Peak current in the inductor, use Equation 45 and Equation 46 to ensure the inductor does not saturate.

Equation 45. LM3478 10135574.png
Equation 46. LM3478 10135575.png

IL1PK must be lower than the maximum current rating set by the current sense resistor.

The value of L1 can be increased above the minimum recommended to reduce input ripple and output ripple. However, once DIL1 is less than 20% of IL1AVE, the benefit to output ripple is minimal.

By increasing the value of L2 above the minimum recommended, ΔIL2 can be reduced, which in turn will reduce the output ripple voltage:

Equation 47. LM3478 10135578.gif

where ESR is the effective series resistance of the output capacitor.

If L1 and L2 are wound on the same core, then L1 = L2 = L. All of the previous equations will hold true if the inductance is replaced by 2L.
