ZHCS840G February   2012  – February 2019 TPS3700

PRODUCTION DATA.

  1. 1 特性
  2. 2 应用
  3. 3 说明
    1.     Device Images
      1.      简化原理图
      2.      输出与输入阈值和迟滞
  4. 4 修订历史记录
  5. 5 Pin Configuration and Functions
    1.     Pin Functions
  6. 6 Specifications
    1. 6.1 Absolute Maximum Ratings
    2. 6.2 ESD Ratings
    3. 6.3 Recommended Operating Conditions
    4. 6.4 Thermal Information
    5. 6.5 Electrical Characteristics
    6. 6.6 Timing Requirements
    7. 6.7 Switching Characteristics
    8. 6.8 Typical Characteristics
  7. 7 Detailed Description
    1. 7.1 Overview
    2. 7.2 Functional Block Diagram
    3. 7.3 Feature Description
      1. 7.3.1 Inputs (INA+, INB–)
      2. 7.3.2 Outputs (OUTA, OUTB)
      3. 7.3.3 Window Voltage Detector
      4. 7.3.4 Immunity to Input Terminal Voltage Transients
    4. 7.4 Device Functional Modes
      1. 7.4.1 Normal Operation (VDD > UVLO)
      2. 7.4.2 Undervoltage Lockout (V(POR) < VDD < UVLO)
      3. 7.4.3 Power-On Reset (VDD < V(POR))
  8. 8 Application and Implementation
    1. 8.1 Application Information
      1. 8.1.1 VPULLUP to a Voltage Other Than VDD
      2. 8.1.2 Monitoring VDD
      3. 8.1.3 Monitoring a Voltage Other Than VDD
      4. 8.1.4 Monitoring Overvoltage and Undervoltage for Separate Rails
    2. 8.2 Typical Application
      1. 8.2.1 Design Requirements
      2. 8.2.2 Detailed Design Procedure
        1. 8.2.2.1 Resistor Divider Selection
        2. 8.2.2.2 Pullup Resistor Selection
        3. 8.2.2.3 Input Supply Capacitor
        4. 8.2.2.4 Input Capacitors
      3. 8.2.3 Application Curves
    3. 8.3 Do's and Don'ts
  9. 9 Power-Supply Recommendations
  10. 10Layout
    1. 10.1 Layout Guidelines
    2. 10.2 Layout Example
  11. 11器件和文档支持
    1. 11.1 器件支持
      1. 11.1.1 开发支持
        1. 11.1.1.1 评估模块
      2. 11.1.2 器件命名规则
    2. 11.2 文档支持
      1. 11.2.1 相关文档
    3. 11.3 接收文档更新通知
    4. 11.4 社区资源
    5. 11.5 商标
    6. 11.6 静电放电警告
    7. 11.7 术语表
  12. 12机械、封装和可订购信息

封装选项

请参考 PDF 数据表获取器件具体的封装图。

机械数据 (封装 | 引脚)
  • DSE|6
  • DDC|6
散热焊盘机械数据 (封装 | 引脚)
订购信息

6.8 Typical Characteristics

at TJ = 25°C and VDD = 5 V (unless otherwise noted)
TPS3700 D002_SLVSCI7.gif
Figure 2. Supply Current (IDD) vs Supply Voltage (VDD)
TPS3700 D004_SLVSCI7.gif
Figure 4. Hysteresis (Vhys) vs Temperature
TPS3700 D006_SLVSCI7.gif
Figure 6. Propagation Delay vs Temperature
(Low-to-High Transition at the Inputs)
TPS3700 D008_SLVSCI7.gif
Figure 8. Supply Current (IDD) vs
Output Sink Current
TPS3700 D010_SLVSCI7.gif
Figure 10. Output Voltage Low (VOL) vs
Output Sink Current (0°C)
TPS3700 D012_SLVSCI7.gif
Figure 12. Output Voltage Low (VOL) vs
Output Sink Current (85°C)
TPS3700 D003_SLVSCI7.gif
Figure 3. Rising Input Threshold Voltage (VIT+) vs Temperature
TPS3700 D005_SLVSCI7.gif
Figure 5. Propagation Delay vs Temperature
(High-to-Low Transition at the Inputs)
TPS3700 D007_SLVSCI7.gif
INA+ = negative spike below VIT–
INB– = positive spike above VIT+
Figure 7. Minimum Pulse Duration vs
Threshold Overdrive Voltage
TPS3700 D009_SLVSCI7.gif
Figure 9. Output Voltage Low (VOL) vs
Output Sink Current (–40°C)
TPS3700 D011_SLVSCI7.gif
Figure 11. Output Voltage Low (VOL) vs
Output Sink Current (25°C)
TPS3700 D013_SLVSCI7.gif
Figure 13. Output Voltage Low (VOL) vs
Output Sink Current (125°C)
