5 Pin Configuration and Functions

VSSOP
10 Pins
Top View

Pin Functions

PIN I/O DESCRIPTION APPLICATION INFORMATION
NAME NO.
D0 1 I Logic Input to set period delay (tDP) Connect to GND (low logic value) or to VDD (high logic value)
D1 2 I Logic Input to set period delay (tDP) Connect to GND (low logic value) or to VDD (high logic value)
D2 3 I Logic Input to set period delay (tDP) Connect to GND (low logic value) or to VDD (high logic value)
VDD 4 P Supply voltage
GND 5 G Ground
DONE 6 I Logic input for Watchdog functionality
TCAL 7 O Short duration pulse output for estimation of TPL5100 timer delay.
MOS_DRV 8 O Drives external MOSFET to power cycle the remaining system.
DNC 9 – Do Not Connect Leave this pin floating
PGOOD 10 I Digital power good input
