6.2.3 Application Curves

at TJ = 25°C unless otherwise noted
TPS65218D0 dcdc1_2_effc_slds206.gif
VOUT = 1.1 V
Figure 6-4 DCDC1/DCDC2 Efficiency
TPS65218D0 dcdc3_eff_2_slds206.gif
VOUT = 1.5 V
Figure 6-6 DCDC3 Efficiency
TPS65218D0 dcdc5_6_eff_slds206.gif
IN_BU = 0 V CC = 3 V
Figure 6-8 DCDC5/DCDC6 Efficiency
TPS65218D0 dcdc3_eff_slds206.gif
VOUT = 1.2 V
Figure 6-5 DCDC3 Efficiency
TPS65218D0 dcdc4_eff_slds206.gif
VOUT = 3.3 V
Figure 6-7 DCDC4 Efficiency
