7.6 Typical Characteristics

TPS543B20 D002_SLUSCR1.gif
VIN = 5 V 500 kHz 25°C
Figure 1. Efficiency vs Output Current
TPS543B20 D003_SLUSCR1.gif
VIN = 12 V 500 kHz 25°C
Figure 3. Efficiency vs Output Current
TPS543B20 D001_SLUSCR1.gif
500 MHz 25°C
Figure 5. Output Current vs Output Voltage
TPS543B20 sluscr1_figure_7_tps543b20.gif
VIN = 12 V 10 A to 20 A to 10 A 10-A Step at 40 A/μs
500 kHz VOUT = 900 mV
Figure 7. Output Voltage Transient Response
TPS543B20 sluscr1_figure_9_tps543b20.gif
VIN = 12 V VOUT = 900 mV 20 A Load
500 kHz
Figure 9. Output Voltage Ripple at Steady State
TPS543B20 sluscr1_figure_11_tps543b20.gif
VIN = 12 V VOUT = 900 mV 20 A Load
500 kHz
Figure 11. Start-Up From EN
TPS543B20 D004_SLUSCR1.gif
VIN = 5 V 500 kHz 25°C
Figure 2. Power Loss vs Output Current
TPS543B20 D005_SLUSCR1.gif
VIN = 12 V 500 kHz 25°C
Figure 4. Power Loss vs Output Current
TPS543B20 D006_SLUSCR1.gif
25°C
Figure 6. Switching Frequency vs Output Current
TPS543B20 sluscr1_figure_8_tps543b20.gif
VIN = 12 V VOUT = 900 mV 0 A Load
500 kHz
Figure 8. Output Voltage Ripple at Steady State
TPS543B20 sluscr1_figure_10_tps543b20.gif
VIN = 12 V VOUT = 900 mV 50 mA Load
500 kHz
Figure 10. Startup From EN
TPS543B20 sluscr1_figure_12_tps543b20.gif
Figure 12. Output Voltage Start-Up and Shutdown
